Description
4K resolution Ultra HD
Media Player Android ™ built-in
BRIGHTNESS AND COLOR WARRANTY
All screens DYNASCAN high brightness, are recognized for their image quality both bright and vibrant, with a degradation of the brightness and color of more than 9% over a period of continuous use of 5 years.
QUALITY AND DEPTH OF THE COLORS
Ensure the color and brightness of each screen in a tiled matrix may take a lot of time and requires hardware calibration additional. Each display is individually calibrated according to the standard CIE color D65 (6500K). This allows you to not only produce a true, natural white, but also guarantee that the color of all screens will be uniform, which is ideal for use in wall of images.
SYSTEM ANTI-NORCISSEMENT (BLACKENING DEFECT FREE)
Most of the screens in both residential and commercial noirciront or will cause a failure in case of overheat of the LCD screen. The DYNASCAN DS851LR4 is equipped with an LCD display, high temperature, capable of withstanding temperatures up to 110° C without darkening – a crucial element for applications in direct sunlight.
AUTOMATIC ADJUSTMENT OF BRIGHTNESS
Different lighting conditions external require different brightness levels. A light sensor built-in measures the ambient light in the area and automatically adjusts the image accordingly.
4K RESOLUTION
With a resolution 4K Ultra HD screen high brightness DS851LR4 provides a extremely sharp for an easy-to-read text and incredible detail
TECHNOLOGY " LOCAL DIMMING BACKLIGHT "
For a better backlight backlight, the screen high brightness DS851LR4 presents a technique of LED backlight dimming local subsidiary for an image that is strikingly contrasted. With the gradation local, direct, darker areas of an image receive less backlighting than lighter areas.
| PANEL | |
| Type of LCD panel | IPS LCD with color 85 inches |
| Native resolution | 3840 x 2160 |
| Brightness | 3 500 nits (max.) |
| Contrast ratio | 3 000:1 (static), 1 000 000:1 (dynamic) |
| Response time | 12 ms (typical) |
| Angle of view | 178° / 178° |
| Life of the light | 50,000 hours (typical) |
| Panel Surface | AG Haze 10%, 3H |
| POWER | |
| Current Source | Internal |
| Rated voltage | 200 V ~ 240 V, 50 Hz / 60 Hz |
| Mode power | 1200 W (typical), 2050 W (max) |
| Energy saving Mode | < 1W |
| AC output | < 100W |
| MECHANICAL SPECIFICATIONS | |
| Width bezel (T/B/L/R) | 26 / 26 / 20 / 20mm |
| Color of cabinet | Black |
| Monitor Dimension (w x h x d, without stand) | 1907 × 1105 × 174 mm |
| Weight of the monitor (set/package) | 115 kg / 130 kg |
| VESA mounting (dimension) | 400x400mm, 1000x400mm |
| USER INTERFACE | |
| Image parameter | Yes |
| Language | English |
| String into a garland | Control DVI + RS-232 |
| Evidence of preservation of the image | Yes |
| Control dimming (DCR) | Yes |
| Built-in support for video wall | Yes – 15 x 15 |
| Parameter identification for the daisy-chain connection | Yes |
| Programming on/off | Yes |
| Ambient light sensor | Yes |
| Time-to-market total market | Yes |
| Portrait and landscape Orientation | Yes |
| Internal temperature sensor | Yes |
| VIDEO INPUT | |
| DVI-D | x1 : 640×480, 720×480, 800×600, 1024×768, 1280×720, 1280×768, 1360×768, 1920×1080 (supports HDCP) |
| HDMI | Optional with adapter |
| ACCESSORIES | |
| Remote control | Yes |
| User's Guide / CD-ROM driver | Yes |
| Video cable | DVI |
| Power cable | Yes |
| SAFETY & ERGONOMICS | |
| CE/FCC/ROHS | |
| ENVIRONMENT | |
| Operating temperature | 0°C ~ 40°C |
| Storage temperature | -20°C ~ 60°C |
| Humidity | 10 % ~ 80 % RH non-condensing |
| All specifications are subject to change without notice. | |
